1. Adopt 11AC wireless technology

Quad-band concurrency, 3800Mbps wireless rate

It supports 2.4G/5G quad-band concurrency, and the number of wireless tape units has been doubled to meet the wireless coverage needs of densely populated places, with a wireless transmission rate of 1200Mbps in the 2.4GHz band and a 2600Mbps wireless transmission rate in the 5GHz band, with a built-in omnidirectional high-gain dual-polarization antenna.

2. Professional hardware and software design

Independent power amplifier circuit to increase the transmit power

The external independent power amplifier circuit (PA) and low noise power amplifier receiving circuit (LNA) further improve the wireless transmission power, reduce the noise interference of wireless signal reception, and have a wider coverage.

Automatic RF tuning optimizes overall performance

It supports automatic radio calibration, automatically calculates the neighbor relationship between APs in the network, and automatically adjusts the wireless transmit power and channel according to the real-time interference and load conditions of nearby devices, ensuring that the overall wireless network is always in a high-speed and high-performance operation state.

Intelligently kick out weak signal devices to improve wireless quality

You can set a weak signal strength threshold to intelligently identify, prohibit, or kick devices whose signal strength is lower than the threshold. Prevent weak signal devices from slowing down network efficiency and improve the roaming quality of the entire wireless network.

Intelligent roaming technology to enhance the wireless experience of every user

The intelligent roaming technology based on the 802.11kvr protocol helps terminal devices such as mobile phones, pads, and computers to automatically connect to the AP with the best signal quality in high-density environments such as conference rooms, office areas, bars, and KTVs, and achieves fast roaming within 50ms, effectively improving the user experience of each user and the overall performance of the wireless network.

3. High-performance interface

Gigabit Ethernet port, higher speed Internet access

Compared with the 100 Gigabit Ethernet port, the speed is greatly improved, so that the wired interface is no longer the bottleneck of wireless transmission, and meets the needs of high-speed Internet access in multi-user and high-bandwidth scenarios.

Gigabit SFP optical port, direct connection is more convenient

One Gigabit SFP fiber module slot is provided to install SFP fiber modules. Optical fiber is directly connected to the AP, which can effectively solve the cabling problem when the AP is far away from the equipment center.

Fourth, the construction is convenient, the management is simple, and the maintenance is worry-free

Multiple power supply methods

a. Standard PoE power supply, more convenient construction

Standard PoE power supply is used, no external power supply is required, and each AP only needs one network cable, which is convenient for construction.

Note: It needs to be used with PoE power supply equipment such as PoE switches and standard PoE power injectors.

b. Passive PoE power supply, power supply transmission distance up to 100 meters

It supports Passive PoE power supply, and the power supply transmission distance can reach 100 meters, which solves the problem of difficult power access in outdoor environments, and flexibly distributes points according to needs.

c. Support 12V~53.5V DC power supply, no need to purchase PoE switches, and reduce networking costs.

Note: This product ships DC power adapter and non-standard PoE power supply module.

Multiple mounting methods

At the same time, it supports pole and wall mounting, and the horizontal and vertical angles can be adjusted, which is simple to install and adapts to more scenarios.

IP68 rated for dust and water resistance

It provides IP68 dustproof and waterproof capabilities, and can work normally in extreme environments as low as -30°C and as high as 65°C, without fear of wind, sun, rain and snow.

Unified management of TP-LINK commercial cloud platform

• Remotely and centrally manage multiple projects, efficient and convenient
• Real-time monitoring of equipment status, timely and accurate alarms
• Graphical data analysis at a glance
• Support mobile APP, management anytime, anywhere

Independent hardware protection circuit, automatically recovering APs that work abnormally

With a built-in independent hardware protection circuit, the AP can automatically recover without manual intervention when the AP is working abnormally, ensuring stable Wi-Fi signal coverage and worry-free maintenance in the later stage.

• 11AC dual-band concurrency, four radios are connected at the same time, and the maximum wireless rate can reach 3800Mbps
• Gigabit SFP optical port, direct connection is more convenient
• Built-in 5dBi omnidirectional antenna, independent RF circuit design, covering a radius of up to 300 meters
• The shell design of the professional room can reach IP68 for waterproof and dustproof, and the working temperature can reach -30°C~65°C, which can adapt to various harsh environments
• Spectrum navigation for better load balance in the 2.4GHz and 5GHz bands
• The power is linearly adjustable, effectively reducing mutual interference between APs
• Automatically rejects weak signal devices to avoid dragging down the entire network and improve wireless network performance
• Independent hardware protection circuit, which can automatically restore abnormal APs
• Passive PoE network cable power supply, flexible distribution
• Pole/wall mounting, flexible and simple

Hardware specifications

Software Specifications (FAT AP Mode)
