The angle of the Mercury II Pro tilt-shift camera lens and sensor plane can be adjusted by 0~8 degrees (horizontal), which can increase the depth of field of the camera when shooting sideways, which is suitable for conditions that require oblique shooting. The ME2P-1230-23U3C-HF8 camera adopts the Sony IMX304 CMOS sensor with global exposure, transmits image data through the USB3.0 data interface, integrates I/O (GPIO) interface, provides cable locking device, and is equipped with screw mounting holes on all sides of the camera, which can be flexibly installed under different structures, and can work stably in various harsh environments, making it a high-reliability industrial digital camera product.
The angle between the camera lens and the sensor plane is adjustable from 0~8 degrees (horizontal)
Trigger Type: Start of Frame / Start of High-Speed Burst of Frame
Two exposure modes: timed exposure mode and trigger width exposure mode
Two time exposure modes: standard exposure time mode and minimum exposure time mode
Gamma, Binning, Decimation
Support digital shift function, black level, flat field correction function
Support sequence function, can preset N groups of different parameters
Ambient light presets, color conversion, and saturation functions are supported
Lookup tables, parameter groups, counters, and timer functions are supported
Remove the parameter range limit, and expand the range value of parameters such as exposure and gain
A 16KB user data area is provided to save algorithm coefficients, parameter configurations, etc
Model | ME2P-1230-23U3C-HF8 |
Brand | Daheng image |
Resolution | 4096×3000 |
Frame rate (fps) | 23.5 |
Inclination direction | Level |
Sensor manufacturers | Sony |
Sensor | 1.1" IMX304 Global shutter CMOS |
Cell size | 3.45μm |
Pixel depth | 8 bit，12 bit |
Data interface | USB3.0 |
Lens mount | C，CS |
Spectrum | Colored |
Image data format | Bayer RG8，Bayer RG12 |
Signal-to-noise ratio | 40.59 db |
Exposure time | Minimum: 1μs ~ 100μs; Standard: 28μs ~ 1s |
Gain | 0db ~ 24db |
Binning | 1×1，1×2，1×4，2×1，2×2，2×4，4×1，4×2，4×4 |
Pixel sampling | Sensor：1×1，2×2 |
Mirror flip | Horizontal mirroring, vertical mirroring |
I/O interface | 1 opto-decoupled input, 1 opto-decoupled output, 2 bidirectional gpios |
Rated power | < 3 W @ 5 VDC |
Power supply requirements | USB 3.0 interface power supply |
Operating temperature | 0°C ~ +45°C |
Storage temperature | -20°C ~ +70°C |
Operating humidity | 10% ~ 80% |
Mechanical Dimensions (W×H×L) | 63 mm × 63 mm × 53.1 mm |
Weight | 143.8 g |
Certifications & Standards | CE，rohs，FCC，USB3 Vision，genicam |
">
