- Stroke30 mm
- Piston diameter80 mm
- Based on standardISO 21287
- CushioningElastic cushioning rings/plates at both ends
- Mounting positionoptional
- DesignPiston Piston rod Profile barrel
- Position detectionVia proximity switch
- Protection against torque/guideGuide rod with yoke
- Operating pressure0.1 MPa ... 1 MPa
- Operating pressure1 bar ... 10 bar
- Mode of operationDouble-acting
- Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
- Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
- Corrosion resistance class CRC2 - Moderate corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Ambient temperature-20 °C ... 80 °C
- Impact energy in end positions1.8 J
- Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke2827 N
- Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke3016 N
- Moving mass888 g
- Product weight1757 g
- Pneumatic connectionG1/8
- Note on materialsRoHS-compliant
- Material collar screwsSteel
- Material coverDie-cast aluminium, coated
- Material sealsTPE-U(PUR)
- Material end plateAnodised wrought aluminium alloy
- Material piston rodHigh-alloy steel
- Material cylinder barrelSmooth-anodised wrought aluminium alloy
