- Stroke1 mm ... 8500 mm
- Piston diameter40 mm
- CushioningElastic cushioning rings/plates at both ends Pneumatic cushioning, adjustable at both ends Shock absorber, hard characteristic curve Shock absorber, soft characteristic curve
- Mounting positionoptional
- GuidePlain-bearing guide Basic guide Recirculating ball bearing guide
- Position detectionVia proximity switch
- VariantsAdditional slide, standard, on left Additional slide, standard, on right
- Operating pressure0.15 MPa ... 0.8 MPa
- Operating pressure1.5 bar ... 8 bar
- Mode of operationDouble-acting
- CE mark (see declaration of conformity)To EU Explosion Protection Directive (ATEX)
- UKCA marking (see declaration of conformity)To UK EX instructions
- Explosion protection certification outside the EUEPL Dc (GB) EPL Gb (GB)
- Explosion protectionZone 1 (ATEX) Zone 1 (UKEX) Zone 2 (ATEX) Zone 22 (ATEX) Zone 22 (UKEX)
- ATEX category gasII 2G
- ATEX category dustII 3D
- Explosion ignition protection type for gasEx h IIC T4 Gb X
- Explosion ignition protection type for dustEx h IIIC T120°C Dc X
- Explosion ambient temperature-10 °C <= Ta <= +60 °C
- Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
- Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
- Corrosion resistance class CRC0 - No corrosion stress 1 - Low corrosion stress 2 - Moderate corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Suitable for use with foodSee supplementary material information
- Ambient temperature-10 °C ... 60 °C
- Cushioning length29.5 mm
- Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke754 N
- Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke754 N
- alternative connectionsSee product drawing
- Type of mountingWith accessories
- Pneumatic connection, clamping unitM5
- Note on materialsRoHS-compliant
- Material coverWrought aluminium alloy
- Material sealsNBR TPE-U(PU)
